Diesel Generator Power by Googol ︳Three Phase
Specifications:(450KVA-3250KVA)
Download PDF: 50HZ Googol Generator 450-3250KVA (National Standards II Emission ).pdf
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Genset
Model | ESP | PRP | Consumption
g/kw.h | L*W*H(mm) | L*W*H(mm) | Engine
Model |
|
|
|
|
|
|
|
|---|
| KVA | KW | KVA | KW |
|
|
|
|
| KGQ450 | 495 | 396 | 450 | 360 | 200 | 3000*1050*1430 | 4300*2100*2300 | PTAA780G1 |
|
|
|
|
|
|
|
| KGQ500 | 550 | 440 | 500 | 400 | 200 | 3150*1050*1430 | 4700*2100*2450 | PTAA780G3 |
|
|
|
|
|
|
|
| KGQ550 | 605 | 484 | 550 | 440 | 200 | 3150*1050*1430 | 4700*2100*2450 | PTAA780G5 |
|
|
|
|
|
|
|
| KGQ688 | 756.8 | 605 | 688 | 550 | 203 | 3230*1400*2050 | 4700*2100*2450 | PTAA1120G3 |
|
|
|
|
|
|
|
| KGQ750 | 825 | 660 | 750 | 600 | 199 | 3700*1400*2050 | 4700*2100*2450 | PTAA1340G3 |
|
|
|
|
|
|
|
| KGQ800 | 880 | 704 | 800 | 640 | 199 | 3800*1600*2100 | 4850*2150*2550 | PTAA1340G5 |
|
|
|
|
|
|
|
| KGQ1000 | 1100 | 880 | 1000 | 800 | 199 | 4500*1800*2100 | 6000*2300*2800 | PTAA1780G5 |
|
|
|
|
|
|
|
| KGQ1100 | 1210 | 968 | 1100 | 880 | 198 | 4500*1800*2100 | REQ | PTAA1780G7 |
|
|
|
|
|
|
|
| KGQ1250 | 1375 | 1100 | 1250 | 1000 | 199 | 5000*2100*2500 | REQ | PTAA2230G1 |
|
|
|
|
|
|
|
| KGQ1375 | 1512.5 | 1210 | 1375 | 1100 | 199 | 5000*2100*2600 | REQ | PTAA2230G3 |
|
|
|
|
|
|
|
| KGQ1650 | 1815 | 1452 | 1650 | 1320 | 194 | 5230*2220*2600 | REQ | QTA3240G5 |
|
|
|
|
|
|
|
| KGQ1875 | 2062.5 | 1650 | 1875 | 1500 | 194 | 5350*2200*2750 | REQ | QTA3240G7 |
|
|
|
|
|
|
|
| KGQ2063 | 2269.3 | 1815 | 2063 | 1650 | 194 | 5800*2220*2750 | REQ | QTA3240G9 |
|
|
|
|
|
|
|
| KGQ2250 | 2475 | 1980 | 2250 | 1800 | 194 | 5900*25002800 | REQ | QTAA4320G3 |
|
|
|
|
|
|
|
| KGQ2500 | 2750 | 2200 | 2500 | 2000 | 194 | 5950*28500*2800 | REQ | QTAA4320G5 |
|
|
|
|
|
|
|
| KGQ2750 | 3025 | 2420 | 2750 | 2200 | 194 | 6000*2560*2900 | REQ | QTAA4320G7 |
|
|
|
|
|
|
|
| KGQ2250 | 2475 | 1980 | 2250 | 1800 | 194 | 6000*2560*2900 | REQ | QTA4320G3 |
|
|
|
|
|
|
|
| KGQ2500 | 2750 | 2200 | 2500 | 2000 | 194 | 6050*2610*2920 | REQ | QTA4320G5 |
|
|
|
|
|
|
|
| KGQ2750 | 3025 | 2420 | 2750 | 2200 | 194 | 6100*2650*3000 | REQ | QTA4320G7 |
|
|
|
|
|
|
|
| KGQ2750 | 3025 | 2420 | 2750 | 2200 | 195 | 8100*3470*3850 | REQ | QTAA5400G1 |
|
|
|
|
|
|
|
| KGQ3000 | 3300 | 2640 | 3000 | 2400 | 194 | 8100*3470*3850 | REQ | QTAA5400G3 |
|
|
|
|
|
|
|
| KGQ3250 | 3575 | 2860 | 3250 | 2600 | 195 | 8100*3470*3850 | REQ | QTAA5400G5 |
|
|
|
|
|
|
|
| KGQ2750 | 3025 | 2420 | 2750 | 2200 | 195 | 8100*3470*3850 | REQ | QTA5400G1 |
|
|
|
|
|
|
|
| KGQ3000 | 3300 | 2640 | 3000 | 2400 | 193 | 8100*3470*3850 | REQ | QTA5400G3 |
|
|
|
|
|
|
|
| KGQ3250 | 3575 | 2860 | 3250 | 2600 | 193 | 8100*3470*3850 | REQ | QTA5400G5 |
|
|
|
|
|
|
|
