8KVA Air Cooled Silent Diesel Generator

Frequency

50HZ

50HZ

Rated Power

5.5KW

6.9KVA

Max Power

6.3KW

7.9KVA

Voltage

230V

230/400V

Current

27.4A

52.2/23.1A

Plugs

16A & 32A

16A & 16A

Display

LED 5 /LED 3

LED 5 /LED 3

Fuel Tank Capacity

13L

22L

Running Time @75% Load

7H

7H

Sound Level

72 dBA @7m

72 dBA @7m

DC Output

12V/8.3A

12V/8.3A

Battery

12V 30Ah

12V 30Ah

Engine

D500E

D500E

Engine Type

Diesel

Diesel

Power

12Hp

12Hp

Start

Electric

Electric

Displacement

498cc

498cc

Oil Capacity

1.75L

1.75L

Alternator

AL6

AL6

Power

6KW

6KW

Power factor

1

0.8

Voltage Regulation

Brush AVR

Brush AVR

Dimension & Weight

Net Weight

154.5Kg

154.5Kg

Gross Weight

162.5Kg

162.5Kg

Machine Dimension

920 x 520 x 740 mm

920 x 520 x 740 mm

Packing Dimension

960 x 560 x 790 mm

960 x 560 x 790 mm

Loading Container

FCL 20 FT/40HQ

48/144

48/144
