Honda Gasoline Generator

Alternator: Standby Power 11KW-13KW
Engine Type: V-type double cylinder, four-stroke, air-cooled, overhead valve
Engine Model: GX630
Auxiliary configuration: Fuel Capacity 25L
Online consultation
Consultation hotline:+65 9825 7795

Product introduction

Honda Gasoline Generator

Installed imported Honda engine, High power, low fuel consumption, easy operation and low noise, Long working hours

Alternators are 100% copper, AVR voltage regulator automatically adjusts the voltage, so that the power is strong and make sure stable output.

Reinforced frame rack, small size, light weight, easy to transport, easy to maintain

Oil protection system, low oil level automatic alarm shutdown, prevents the engine from working at low oil levels and gives the engine more protection

Better sound insulation, small size, good appearance, anodized surface treatment, the body is anti-radiation, rain-proof, frost-resistant, high temperature resistant, and more durable


Genset
Model
BH12000BH15000
AlternatorStandby Power11KW13KW
Prime Power10KW12KW
Frequency 50HZ50HZ
Rated Voltage 230V230/400V230V230/400V
Max Current47.8A12.3A /Phase56.5A18.8A /Phase
Phase1P3P1P3P
Power Factor (Cosφ)1.00.81.0 0.8

Insulation ClassFF
EngineEngine ModelGX630GX690
Bore x Stroke78×70mm78×70mm
Displacement 630cc690cc
Fuel Consumption ≤312g/kw.h≤312g/kw.h
Ignition MethodTransistor electronic ignitionTransistor electronic ignition
Engine TypeV-type double cylinder, four-stroke, air-cooled, overhead valveV-type double cylinder, four-stroke, air-cooled, overhead valve
Oil Capacity 1.3L1.5L
Startup modeElectric StartElectric Start
Auxiliary configurationFuel Capacity25L25L
Battery Capacity12V-36AH maintenance-free battery12V-36AH maintenance-free battery
Oil Alarm

Fuel Indicator

Control PanelDigital displayDigital display
OthersNoise Level75dBA/7m75dBA/7m
Overall Size(mm)950x620x650950x620x650
Con. Working Time8h8h
Weight160Kg165Kg
