Kholer Gasoline Generator

Alternator materials: Copper
Engine Model: CH640
Engine: Oil Capacity 1.9L
Engine: Fuel Consumption ≤374g/kw.h

Online consultation

Consultation hotline:+65 9825 7795

Product introduction

Installed imported Kholer engine, High power, low fuel consumption, easy operation and low noise, Long working hours

Alternators are 100% copper, AVR voltage regulator automatically adjusts the voltage, so that the power is strong and make sure stable output.

Reinforced frame rack, small size, light weight, easy to transport, easy to maintain

Oil protection system, low oil level automatic alarm shutdown, prevents the engine from working at low oil levels and gives the engine more protection

Better sound insulation, small size, good appearance, anodized surface treatment, the body is anti-radiation, rain-proof, frost-resistant, high temperature resistant, and more durable

Genset Model		KPK1110		KPK1140		KPK1160		KPK1180
Alternator	Standby Power	11KW		13KW		16KW		20KW
	Prime Power	10KW		12KW		15KW		18KW
	Frequency	50HZ		50HZ		50HZ		50HZ
	Rated Voltage	230V	230/400V	230V	230/400	230V	230/400V	230V	230/400V
	Max Current	47.8A	12.3A/Phase	56.5A	18.8A/Phase	69.5A	23.2A/Phase	87A	29A/ Phase
	Phase	1P	3P	1P	3P	1P	3P	1P	3P
	Power Factor (Cosφ)	1.0	0.8	1.0	0.8	1.0	0.8	1.0	0.8
	Insulation Class	F		F		F		F
Engine	Engine Model	CH640		CH740		CH790		CH980
	Bore x Stroke	80×67mm		83×69mm		90×78.5mm		90×78.5mm
	Displacement	674cc		725cc		999cc		999cc
	Fuel Consumption	≤374g/kw.h		≤374g/kw.h		≤385g/kw.h		≤385g/kw.h
	Ignition Method	Transistor Electronic Ignition		Transistor Electronic Ignition		Transistor Electronic Ignition		Transistor Electronic Ignition
	Engine Type	V-type double cylinder, four-stroke, air-cooled, overhead valve		V-type double cylinder, four-stroke, air-cooled, overhead valve		V-type double cylinder, four-stroke, air-cooled, overhead valve		V-type double cylinder, four-stroke, air-cooled, overhead valve
	Oil Capacity	1.9L		1.9L		1.9L		1.9L
	Startup mode	Electric Start		Electric Start		Electric Start		Electric Start
Auxiliary configuration	Fuel Capacity	25L		25L		30L		30L
	Battery Capacity	12V/36Ah		12V/36Ah		12V/36Ah		12V/36Ah
	Oil Alarm
	Fuel Indicator
	Control Panel	Digital Display		Digital Display		Digital Display		Digital Display
Others	Noise Level	75dBA/7m		75dBA/7m		80dBA/7m		80dBA/7m
	Overall Size	950x620x620mm		950x620x620mm		1050×670×750mm		1050×670×750mm
	Con. Working Time	8h		8h		6h		6h
	Weight	170Kg		175Kg		190Kg		200Kg
